Description
The TSC TX610 Desktop Barcode Printer is a high-resolution 600 DPI label printer, designed for precision printing in applications such as fine jewelry, product marking, compliance labeling, and electronics label marking. With thermal transfer and direct thermal printing, the TX610 delivers sharp and accurate prints for barcodes, graphics, and small text. Its rugged double-walled clamshell design, USB, RS232, and Ethernet connectivity, and intelligent printhead technology make it a reliable and efficient choice for businesses. Supporting SOTI Connect and TSC Console, it enables remote printer management, enhancing productivity and operational efficiency.
Product Features
- Ultra-High Resolution Printing – 600 DPI resolution ensures sharp, detailed labels for small text and graphics.
- Versatile Connectivity – USB 2.0, RS232, and Ethernet allow seamless integration into any workspace.
- Durable & Rugged Build – Double-walled clamshell housing ensures long-lasting performance.
- Efficient Ribbon System – Supports 300m ribbon capacity, reducing downtime and improving efficiency.
- Multi-Application Printing – Ideal for fine-jewelry labeling, product marking, compliance labels, and more.
- User-Friendly Interface – Multi-icon LED display for quick status updates (optional 3.5” color LCD for enhanced control).
- Advanced Printhead Technology – Self-Diagnostic TPH Care detects and compensates for printhead errors.
- Remote Management Ready – Supports SOTI Connect and TSC Console for centralized printer monitoring.
- Flexible Media Handling – Compatible with continuous, die-cut, black mark, fan-fold, and notch labels.
Product Specifications
| Printing Method | Thermal Transfer & Direct Thermal |
| Resolution | 600 dpi (24 dots/mm) |
| Max Print Speed | 4 ips (102 mm/sec) |
| Max Print Width | 4.17" (106 mm) |
| Max Print Length | 100" (2,540 mm) |
| Media Type | Continuous, die-cut, black mark, fan-fold, notch |
| Media Width | 0.75” – 4.4” (19 – 112 mm) |
| Media Roll Capacity | 5” (127 mm) OD |
| Ribbon Capacity | 300m length, 1" core, 67 mm OD |
| Memory | 128 MB SDRAM, 128 MB Flash (Expandable via microSD up to 32GB) |
| Interfaces | USB 2.0, RS232, Ethernet |
| Sensors | Transmissive gap, black mark reflective, ribbon end, ribbon encoder, head open |
| Processor | 32-bit RISC CPU |
| Display | LED panel with status icons (Optional: 3.5” color TFT LCD) |
| Power Supply | AC 100-240V, 50-60Hz |
| Dimensions (W x H x D) | 226 mm x 200 mm x 332 mm (8.9” x 7.87” x 13.07”) |
| Weight | 4.08 kg (8.99 lbs) |
| Printer Languages | TSPL-EZD (Compatible with EPL, ZPL, ZPL II, DPL) |
| Operating Temperature | 5 – 40°C, 25 – 85% RH (non-condensing) |
Features
Print Speed:
- 102mm/sec
Brand:
TSC
Interface:
- USB
- Serial/RS232
- Ethernet
OS Compatibility:
- Windows
- Android
Warranty (Years):
- 3
Product Type/Condition:
- New
Print Method:
- Direct Thermal
- Thermal Transfer
Print Resolution-DPI:
- 600
Max Print Width:
- 4 inch
Print Type:
- Monochrome
Printer Type:
- Desktop
