Description
The TSC Alpha-40L Linerless Mobile Label Printer is a rugged, high-performance direct thermal mobile printer designed for seamless and efficient label printing. Engineered for enterprise professionals, this printer features MFi Bluetooth® 5.0, and NFC tap-to-pair. The IP54-rated durable design makes it resistant to dust and water, while its smart battery technology and remote management compatibility (SOTI Connect & TSC Console) maximize productivity. Ideal for retail, logistics, healthcare, and manufacturing, the Alpha-40L offers an intelligent and eco-friendly printing solution with its linerless printing capability.
Product Features
- Smart & Durable Design – IP54-rated dust and water resistance with a drop tolerance of 1.8m (2.5m with protective case)
- Seamless Wireless Connectivity – MFi Bluetooth® 5.0, and NFC tap-to-pair.
- Linerless Printing Compatibility – Supports linerless media for eco-friendly, waste-reducing printing
- High-Speed Printing – Fast and efficient 5 inches per second (ips) printing speed
- Remote Printer Management – Integrated with SOTI Connect and TSC Console for easy monitoring and maintenance
- Enterprise-Level Battery Performance – 7.4V DC, 6,200 mAh rechargeable Li-ion smart battery for extended operations
- User-Friendly Interface – 2.3" color LCD display with intuitive navigation buttons for easy operation
- Comprehensive Software Support – Compatible with Windows™, Android™, iOS SDKs, and TSC Mobile Utility App
- Versatile Media Handling – Built-in peeler and factory option for linerless kit for hassle-free label dispensing
- Wide Application Use – Perfect for retail, logistics, healthcare, and manufacturing label printing needs
Product Specification
| Printing Method | Direct Thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Max. Print Speed | 5 ips |
| Max. Print Width | 104 mm |
| Max. Print Length | 2,794 mm (110") |
| Enclosure | Plastic with rubber over-molding |
| Dimensions (W x H x D) | 160 mm x 191 mm x 79 mm |
| Weight (with Battery) | 985 g |
| Drop Specification | 1.8m (with protective case: 2.5m) |
| IP Rating | IP54 (without case, paper path excluded) |
| Max. Roll Capacity | 67 mm OD |
| Processor | 32-bit RISC CPU |
| Memory | 128 MB SDRAM, 128 MB Flash (Expandable via microSD up to 32 GB) |
| Display | 2.3” Color LCD (320 x 240 pixels) |
| Connectivity Options | USB Type-C, MFi Bluetooth® 5.0, NFC |
| Sensors | Reflective, Transmissive, Peel, Head Open |
| Battery | 7.4V DC, 6,200 mAh Li-ion Smart Battery |
| Supported Barcode Types | 1D: Code128, EAN13, Code39, ITF14, etc. / 2D: QR Code, PDF417, DataMatrix, etc. |
| Media Type | Die-cut, Black Mark, Receipt, Fan-Fold, Linerless, Continuous |
| Media Width | 50.8 ~ 112 mm |
| Media Core Diameter | 12.7 mm (Standard) / 19.1 mm (with adapter) |
| Operating Temperature | -20 ~ 50°C |
| Software Support | Windows™, iOS, Android™, TSPL-EZC (EPL2, ZPL2, CPCL), ESC-POS |
Features
Print Speed:
- 5
Brand:
TSC
Interface:
- USB-C
- NFC
- Bluetooth
OS Compatibility:
- Windows
- IOS
- Android
Rugged:
- Rugged/Heavy Duty
IP Rating:
- IP54
Warranty (Years):
- 2
Product Type/Condition:
- New
Print Method:
- Direct Thermal
Print Resolution-DPI:
- 203
Max Print Width:
- 4 inch
Print Type:
- Monochrome
Printer Type:
- Mobile/Portable
