Description
The Datalogic Gryphon GM4500 is a premium cordless 2D imager scanner, designed for high-performance scanning in general-purpose applications. With STAR Cordless System (433 MHz), a 1 Megapixel sensor, and Datalogic’s renowned Green Spot and 3GL™ technology, it ensures fast, accurate reads across a wide range of 1D and 2D barcodes.
Built with a sleek white Disinfectant-Ready housing, the GM4500 is ideal for demanding environments such as healthcare, retail, light manufacturing, and commercial services. Its IP52-rated durability, ergonomic design, and wireless battery charging make it a reliable and efficient scanning solution. Battery is included, while the charging/transmitter cradle is sold separately.
Product Features
- Premium 2D imager with 1 Megapixel optical resolution
- Datalogic Green Spot and 3GL™ (Three Green Lights) for excellent read feedback
- STAR Cordless System (433 MHz) for reliable radio communication
- Wireless charging technology with inductive system – no contact points
- Reads all standard 1D, 2D, postal, stacked, composite, and Digimarc barcodes
- Motionix™ motion-sensing for automatic scanning mode transitions
- Long-lasting, user-replaceable 3250mAh Lithium-Ion battery (included)
- Omnidirectional scanning and document capture functionality
- IP52-rated for dust and water resistance
- Disinfectant-Ready housing – ideal for healthcare and clean environments
Product Specifications
| Scanner Type | Cordless 2D Imager |
| Communication | STAR Cordless System, 433 MHz |
| Optical Sensor | 1 Megapixel (1280 x 800 pixels) |
| Aiming System | Red laser (650 nm) |
| Illumination | White light |
| Feedback | Green Spot, 3GL™, Vibration, Beeper |
| Motion Tolerance | 35 IPS |
| Reading Technology | Omnidirectional, Motionix™ auto-sensing |
| Battery | Lithium-Ion 3250 mAh (included) |
| Charging Method | Wireless inductive charging (cradle sold separately) |
| Reads | 1D, 2D, Postal, Stacked, Composite, Digimarc codes |
| Interfaces | RS-232, USB, Keyboard Wedge (Multi-Interface) |
| Operating Temperature | 0°C to 50°C |
| Drop Resistance | 1.8 m / 6 ft onto concrete |
| Sealing Rating | IP52 |
| Dimensions | 16.6 x 6.8 x 10.9 cm |
| Weight | 235 g |
| Colour | White |
| Warranty | 3-Year Factory Warranty |
Features
Connectivity:
- Wireless
Form Factor:
- Handsfree
Scan Engine/Technology:
- 2D Imager
Interface:
- Keyboard Wedge
- USB
- Serial/RS232
Colour:
- White
IP Rating:
- IP52
Warranty (Years):
- 3
